The Knowlege of Rain Spray corrosion test

rain spray chamber/feature:

1. Water pressure and flow rate adjustable.

2. Unique sprinkler can stably control the rain quantity and pressure.

3. This equipment (Model B) can make the test products' temperature rising from RT-85celsius degree

4. Inner case's material is imported steel plates, Shell is made of #304 stainless steel.

5. This equipment applies rain spray test for products and parts.

rain chamber/technical parameters:

1.Model:RT-1000A:RT-1000B

2.Test Standard:JIS, ISO, IEC60529, DIN40050, GB2423, GB4208 standard

3.Internal DimensionWxHxD (mm):1000x1000x1000

4.External Dimension WxHxD (mm): 1600x1900x1400

5.JIS Test: Flow 1.8L/Min~3.9L/Min,pressure 0.1kgf/cm2~0.3 kgf/cm2

     Flow 24.5L/Min~39.2L/Min,Pressure 1kgf/cm2~3 kgf/cm2

6.Drop Test: 1~1.5mm/Min Adjustable ;IPx1 IPx2 drop speed1~1.5mm/Min adjustable; 3~3.5mm/Min Adjustable drop speed 3~3.5mm/Min adjustable

7.Rain of Pipe-Swing Test: IPx3 IPx4 swing pipe RT~±80celsius degree;Flow 0.07L/min per Nozzle

8.Water Spray Test:IPx3 IPx4 jet:2.5m~3m;flow 12.5L/min ~100L/Min

9. High Pressure Jet Test:80Kgf~100Kgf;IPx9K pressure of jet:80Kgf~100Kgf

Flow 14~16L/Min

10.Rotating Speed of Rotating-Plate: 4~20 RPMadjustable

1.IPX1, IPX2 test

IPX1, X2 Negative pressure to absorb design

Unique nozzle, not easy to block

2.IPX3, IPX4 test

Pipe swing-type designed with gear motor, angle and speed adjustable.

Nozzle Angle aiming at the circle center

3.IPX5, IPX6 test

IPX5, IPX6 titanium alloy Nozzle

Water column non-proliferation

Certificate of these machines:

China official 3rd party calibration report

CE certiification

For the package:

1. PP film first

2. Vacuum package

3. PP film again

4. 10mm thickness PU foam to avoid collision

5. stronged plywood case

6. Standard ASLI CASE MARK

Our Main Products:

1) temperature humidity chamber

2) temperature fast change chamber (ESS chamber)

3) thermal shock chamber

4) temperture humidity combined salt spray chamber

5) temperture humidity combined vibration chamber

6) pressure accelerated aging chamber (PCT&HAST chamber)

7) high temperature aging chamber

8) sand and dust tester

9) rain/water spray chamber

10) salt spray chamber

11) UV climate resistant chamber

12) high temperature chamber/muffle furnace

13) vacuum oven

14) high frequency vibration tester

15) mechanical shock and impact tester

16) acceleration mechanical shock tester

Pls feel free to contact us for detail technical parameters.
